SmartTrailer
Schmitz Cargobull's innovative SmartTrailer concept combines the advantages of trailer telematics with proven vehicle equipment to create an efficient transport solution.
Your benefits
-
Intelligent connectivity of all trailer components, including cooling unit, running gear, EBS, brakes, tyres and locking systemΔιαβάστε περισσότερα
-
Central display and operation of sensors and actuators via the TrailerConnect® online portal, the beSmart app and the Schmitz Cargobull S.CU cooling unit display panelΔιαβάστε περισσότερα
-
Fast diagnostics of all components with the telematics control unitΔιαβάστε περισσότερα
Six good reasons for TrailerConnect®
-
Ongoing process optimisation- Advanced notice of the wear and status of technical axle units prevents breakdowns and shortens the time required for service stops
Διαβάστε περισσότερα -
Intelligent vehicle management- Overview of trailer location and availability
- Proof of just-in-time deliveries
- Improved capacity utilisation, avoidance of empty runs
Διαβάστε περισσότερα -
Long-term reduced costs- Increased transparency and efficiency reduce costs, offering faster payback
Διαβάστε περισσότερα -
Excellent transport safety and security- Continuous information about the door and coupling status
- Configurable alarm messages in real time
- Control of the door locking mechanism
Διαβάστε περισσότερα -
Reliable temperature management- Active temperature monitoring with real-time alarm function
- Recording and archiving of all temperature data
- Two-way communication including certified temperature recording function in accordance with DIN EN 12830
Διαβάστε περισσότερα -
Optimised CO2 emissions- Avoidance of empty runs
- Optimised vehicle capacity utilisation
Διαβάστε περισσότερα
TrailerConnect® control unit
The TrailerConnect® control unit is the heart of our telematics system. Universal opportunities for use ensure maximum flexibility.
- Maximum functional safety to automotive standard in line with the highest protection rating, IP69K
- Fully functional between -40 ?C and + 85 ?C
- Robust construction for a long service life and use under extreme conditions
- Simple and convenient diagnostics using professional software for shorter service interruptions
- Modular, scalable system: from a basic solution to fully equipped
TrailerConnect® components
-
Safe Investments
-
Optional sensor system
-
Cooling unit operating data
- The connected braking system transmits status, operational information and diagnostic data
Διαβάστε περισσότερα -
Temperature recorder
- The telematics control unit and up to six cargo area sensors ensure that the temperature is recorded in accordance with DIN EN 12830
Διαβάστε περισσότερα -
Wi-Fi
- A Wi-Fi module integrated in the control unit enables the beSmart app to display information and operate the cooling unit
Διαβάστε περισσότερα -
Telematics battery
- The telematics battery, which can be heated for charging, ensures standby times in decoupled state
Διαβάστε περισσότερα -
EBS operating data
- The connected braking system transmits status, operational information and diagnostic data
Διαβάστε περισσότερα -
Motion sensor
- An acceleration sensor in the telematics control unit identifies when the trailer is static or moving
Διαβάστε περισσότερα
-
Tyre pressure monitoring system
- Rim-mounted sensors measure tyre pressure and temperature and transmit this to a receiver in the telematics control unit
Διαβάστε περισσότερα -
Fuel tank sensor including display
- A sensor integrated in the fuel tank records and monitors the level of diesel in the cooling unit, even when it is switched off
Διαβάστε περισσότερα -
Tractor detection
- An RFID receiver on the front wall identifies the RFID transponder on the tractor
Διαβάστε περισσότερα -
Coupling sensor
- A coupled tractor is reliably detected by monitoring the brake supply pressure
Διαβάστε περισσότερα -
Temperature printer
- A printer on the front wall enables printing of temperature data
Διαβάστε περισσότερα -
Brake pad wear display
- New brake pad wear sensors record the brake wear, including the wheel position
Διαβάστε περισσότερα -
Battery monitor
- A separate hardware component monitors the status of the cooling unit battery
Διαβάστε περισσότερα -
Locking system
- A locking system integrated in the rear portal enables full access control and remote control using telematics
Διαβάστε περισσότερα -
Precision odometer
- An ABS sensor and GPS help to calculate the precise mileage (km), even when the EBS spiral cable is not inserted
Διαβάστε περισσότερα -
Door contact switch
- An electronic sensor integrated in the rear portal monitors the status of the doors, even when uncoupled
Διαβάστε περισσότερα
Telematics retrofitting
- Retrofitting of a telematics system is feasible in principle, once the technical requirements have been checked.
- For older trailers and other manufacturers' trailers in existing fleets.
- Simply get in touch with us: Tel. +49 2558 81-1818 or Mail: helpdesk@trailerconnect.de
TrailerConnect® beSmart app - to operate the SmartTrailer
The beSmart app ensures that your drivers are always aware of the status of the trailer and can react quickly if necessary. The integrated Wi-Fi module in the trailer provides communication between the telematics control unit and a smartphone. You'll never miss important news or messages again.
- Cargo area temperature analysis: View the current temperature on your smartphone and control the temperature printer directly from your smartphone
- Monitoring and control of the cooling unit: Keep an eye on the cooling unit's operating data
- Brake pad wear monitoring: Avoid breakdowns and plan your workshop visits efficiently. The beSmart app shows you the status of your brake pads
- Axle load: Improve safety on the road and reduce the wear and tear on your trailer. Check whether the axle load matches the delivery paperwork
- Tyre status monitoring: Avoid flat tyres and increased tyre wear by keeping an eye on tyre pressure and tyre temperature
- Rear door locking system: Control the PIN-protected door locking system easily and conveniently via the beSmart App
Operating Manual
Here you will find information on how to connect the beSmart App with the SmartTrailer, detailed descriptions of the individual functions and numerous tips on how to use the App.
Click here for the operating manual for the beSmart App
Media
-
Operating Manual beSmart App
-
TrailerConnect Telematic - Short Information
-
Schmitz Cargobull telematics - Brochure
FAQ
-
Τι είναι αυτό που μετατρέπει το σύστημα τηλεματικής TrailerConnect® ειδικά σε S.KO Cool Smart σε καινοτόμο εξοπλισμό;Το σύστημα τηλεματικής βοηθάει το τρέιλερ έτσι ώστε πολλές διαδικασίες παρακολούθησης και χειρισμού οχήματος να πραγματοποιούνται με πολύ μεγαλύτερη αποδοτικότητα και διαφάνεια και να επιτυγχάνεται με τον τρόπο αυτό σημαντική βελτιστοποίηση.
-
Ποια πλεονεκτήματα προσφέρει το σύστημα OEM;Όλα τα εξαρτήματα δικτυώνονται μεταξύ τους με ιδανικό τρόπο στο τρέιλερ, έχουν σχεδιαστεί κατάλληλα το ένα για το άλλο και έχουν εγκατασταθεί με επαγγελματικό τρόπο σύμφωνα με τα στάνταρτ της αυτοκινητοβιομηχανίας. Το γεγονός αυτό διασφαλίζει άριστη ποιότητα και απόλυτη διαθεσιμότητα συστήματος.
-
Εκτός από αναφορά θέσης, τι άλλο πρέπει να προσφέρει το σύστημα τηλεματικής τρέιλερ;Εκτός από την αναφορά θέσης, ένα σύστημα τηλεματικής τρέιλερ πρέπει να διαθέτει έξυπνη δικτύωση και γρήγορη διάγνωση όλων των εξαρτημάτων τρέιλερ αλλά και ασφαλή και ενσωματωμένη διαχείριση θερμοκρασίας. Με το σωστό σύστημα τηλεματικής μπορείτε να βελτιστοποιήσετε και τις διαδικασίες αλλά και να αυξήσετε την ασφάλεια μεταφοράς.
